Product Details:
|
| Keyword: | Putzmeister 46M Used Concrete Pump | Productivity: | 150M³/H |
|---|---|---|---|
| UNIQUE SELLING POINT: | High Operating Efficiency | AHydraulic System Oil Pressure: | Building Material Shops, Machinery Repair Shops |
| Total Weight: | 44450.000 Kg | Dimension(L*W*H): | 11955*2500*3990mm |
| High Light: | 46M Used Concrete Pump,Isuzu Truck Used Concrete Pump |
||
Putzmeister 46M Used Concrete Pump For Isuzu Truck
|
Distribution valve |
S-valve |
|
|---|---|---|
| Max. Concrete Output | m3/h | 200/140 |
| Max. Concrete Pressure | bar | 83/120 |
| Delivery Cylinder | mm | 260 |
| Stroke Length | mm | 2100 |
| Strokes | 1/min | 30/21 |
| Hopper Capacity | L | 600 |
| Filling height | mm | 1540 |
| Hydraulic System | Closed | |
| Hydraulic oil cooling | Double fans | |
| High/Low Press. Switch | Manual | |
| Lubrication on pump | Automatic | |
| Lubrication on hopper | Automatic | |
| GPS Data Manage | Optional | |
• Compact in design, 60m pump mounted on 5-axle truck.
• Efficient pump unit, two Rexroth main pumps gives a big output, easy to use and maintenance.
• Agile placing boom with 6 arms with unfolding height 14m only, which gives a wide work range.
• One side lateral support enables to work in narrow sites.
Q1:Which country do you export to?
Asia:India,Philippines,Thailand,Burma,Vietnam,Bangladesh,Kazakhstan,Turkmenistan,etc.
Middle east:Saudi Arabia,UAE,Jordan,Oman,Pakistan,etc.
Europe:Russia,Ukraine,Belarus,Bulgaria,etc.
Africa:South Africa,Kenya,Congo,Ethiopia,Nigeria,Ghana,Algeria,Senegal,Tunisia,etc.
South America:Brazil,Peru,Chile,Cuba,Venezuela,Mexico,etc.
Oceania:Papua New Guinea,Australia,etc.
Q2:What is the proportion of your products export?
75% of our products are exported to all over the world.
Q3:What is the payment term?
Payment term is negotiable and there will be favorable payment terms for long-term customers.TT,L/C,D/P,depending on the cooperation time,country and contract value.
Q4:What kind of logistic service do you supply?
FOB,CIF,DAP,ETC.
